Key features of the PROVA CM-01 include: - Minimum display of 0.001A, suitable for small current measurements. - High-resolution measurements for both AC and DC currents. - Max/Min value function with real-time data updates. - Low battery indication to ensure the device is always ready for use.
Product Introduction
PROVA CM-01 AC clamp meter can measure weak AC current。 AC clamp meter can measure the AC current of the equipment, and the minimum display is 0.001A.
Measurement Specification
Digits Dispaly : 3,999 Digits
Clamp Caliber : Ø23 mm
DCA 0-40A : 10mA +/- 1.0% +/- 2dgts
DCA 0-150A : 100mA +/- 1.0% +/-2 dgts
DCA 150-200A : 100mA -2.2% +/- 2dgts
DCA 150-200A : 100mA -2.2% +/- 2dgts
AC Current 0-40A : 10mA +/- 1.0% +/- 3 dgts
AC current 0-150A : 100mA +/- 1.0% +/- 3 dgts
AC Current 150-200A : 100mA -2.2% +/- 3dgts
AC Current 150-200A : 100mA -2.2% +/- 3dgts
AC Voltage : 400 V
DC Voltage : 600 V
Frequency : 100~1000K Hz
Current Resolution : DC: 0.01A / AC: 0.01A
Voltage Resolution : DC: 0.1V / AC: 0.1V
Current Accuracy : DC: ±(2%+5 value) / AC: ±(2%+5 value)
Voltage Accuracy : DC: ±(1%+2 value) / AC: ±(1.5%+2 value)在 50/60Hz
Sampling Rate : Figure:２times / Sec. ／ Graph: 20 times / Sec.
Product Features
BEEPER :
RESET BUTTON (ZERO) :
DATA HOLD (HOLD) :
MAXIMUM / MINIMUM (MAX/MIN) :
ANALOGE BAR : 40 Segment
Product Information
Working Environment : 0~50°C / lower than 85%RH without dew。
Storage Environment : -10~50°C / lower than 75%RH without dew。
Elevation Limitation : Lower than 1,000 meters
Power Supply : 1.5v Battery (AA) x 2
Dimension : 180 × 63.6 × 35.6 mm
Weight : 190g (Battery including)
Accessory : Battery x2、Test Lead、 Carrying Bag、Manual
